Memory device is serial eeprom 95c160 SSOP8 package.
Expected file size is 2048 bytes.
Use PCF7936 or Silca T14 – JMA TP12 transponder or remote key.
IMPORTANT when you want to program remote key :open key and look on PCB.
You will find 2 SMD chips – PCF7946 (SMD 14 pins) and smaller SMD chip, which can be with 8, 10, or 16 pins.
If smaller SMD chip is with 10 or 16 pins, PROGRAM KEY AS TYPE 1.
If smaller SMD chip is with 8 pins, PROGRAM KEY AS TYPE 2.
IMPORTANT:if buttons of remote operate, but not work properly, for ex. button for locking opens trunk, this is NOT A TMPro SOFTWARE PROBLEM. Use other type remote.
Module also shows PIN code
Written transponder is ready programmed to start the vehicle.
Expected file size is 2048 bytes.
Use PCF7936 or Silca T14 – JMA TP12 transponder or remote key.
IMPORTANT when you want to program remote key :open key and look on PCB.
You will find 2 SMD chips – PCF7946 (SMD 14 pins) and smaller SMD chip, which can be with 8, 10, or 16 pins.
If smaller SMD chip is with 10 or 16 pins, PROGRAM KEY AS TYPE 1.
If smaller SMD chip is with 8 pins, PROGRAM KEY AS TYPE 2.
IMPORTANT:if buttons of remote operate, but not work properly, for ex. button for locking opens trunk, this is NOT A TMPro SOFTWARE PROBLEM. Use other type remote.
Module also shows PIN code
Written transponder is ready programmed to start the vehicle.
Vehicles equipped with this unit:
Fiat: Bravo(2007-), Ducato(2006-), Stilo(2007-), Punto(2007-), Idea(2008-)
Citroen: Jumper(2006-), Relay(2006-)
Peugeot: Boxer(2006-)
Lancia: Ypsilon(2007-), Musa(2007-)
Fiat: Bravo(2007-), Ducato(2006-), Stilo(2007-), Punto(2007-), Idea(2008-)
Citroen: Jumper(2006-), Relay(2006-)
Peugeot: Boxer(2006-)
Lancia: Ypsilon(2007-), Musa(2007-)
